Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles

Name: Alinta 8feet SMT Slide Switch 150gf100gf 10000 Cycles
Brand: Alinta
Price: 1 USD

Quality Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles for sale

Brand Name : Alinta

Model Number : QC-AY08AG456-R

Certification : RoHS,REACH

Place of Origin : CN

MOQ : 1000

Price : Negotiable

Payment Terms : T/T

Supply Ability : 25KK per month

Delivery Time : 5-8 days

Packaging Details : Tape & Reel

Termination Type : SMT, 8-feet

Operation Force : 150gf±100gf

Life Cycle : 10000

Travel : 2mm

Contact Now

Product Type: QC-AY08AG456-R

Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles

/Parameter

Current/Voltage Rating	DC 12V 200mA
Insulation Resistance	≥100MΩ
Contact Resistance	≤100mΩ
Life Cycle	10000
Withstand Voltage	500V AC Min
Operating Temperature	-20 to 85°C
Operation Force	150gf±100gf
Solderability	255°C Max Solder Temperature

/Material

Button	PA46 Black
Cover	SUS
Shrapnel	Beryllium Bronze, AG plating
Terminal	Brass, AG plating
Housing	PA6T Black

/DIMENSION/SCHEMATIC

Alinta 8-feet SMT Slide Switch 150gf±100gf 10000 Cycles

/Market/Application

Audio/TV, Mobile, Healthcare, Home Appliance, Smart Meter, Energy/Industrial Equipments

/Production Overview

CCD Inspection Equipment

--------------------------------------------------------
ALINTA Factory boasts a fully automated production line for sliding switches and advanced inspection equipment, supported by a rigorous management system and professional personnel, ensuring that every product delivered to our customers is safe and reliable.
Welcome to contact us for any product inquiries and welcome to visit our factory in China.
